MATTHEW FREDRICKS
PCB Design · Embedded Systems · CAN Networks · Power Electronics · Industrial Machine Design. EE @ Montana State, FSAE Electrical Systems Lead.
Featured Work
LoomFlow — Wire Harness Design Tool
A schematic-first wire harness editor — drag to connect and the BOM, cut list, pinouts, and drawing sheets derive themselves. Browser demo live; Windows desktop app in progress.
Distributed Vehicle Data Acquisition Node
Corner-node CAN sensor network on a chip-down ESP32-S3, 4-layer board — 24-bit strain/RTD acquisition, reconfigurable inputs, DBC-first firmware.
FSAE Power Distribution Module
9-channel solid-state PDM with PROFET high-side switching, per-channel current sense, and CAN control.
Teensy 4.1 DAQ & Telemetry Gateway
Central data acquisition gateway — dual CAN, SD logging, LoRa telemetry at 915 MHz, Raspberry Pi dashboard.
CBR600RR Engine Management Bring-Up
Speeduino Dropbear v2 on a CBR600RR — wasted-spark LS coils, 12-1 crank trigger, injector driver repair.
Low-Cost FSAE Wire Harness (v1)
An extremely low-cost first-generation engine/chassis wire harness for our FSAE internal-combustion car — and a crash course in doing it right.
